Excavator Concrete Breaker Hydraulic Breaking Hammer For Excavator
(1) Excavator concrete breaker in the concrete field
Excavator concrete breaker widely used in the concrete field like:
1. Building demolition;
2. Concrete structures demolition and recycling;
3. Concrete road surface breaking.
(2) With what excavator models excavator concrete breaker 53mm could work?
Excavator concrete breaker with breaker chisel 53 mm belongs to light-duty hydraulic breakers,
which could work with world-famous excavator brands like:
XCMG40
VOLVO EC30/35/25 ZL302
KUBOTA 35
KOBELCO SK035
SUNWARD SWE30/40
HITACHI EX25/27/30/33/34 UE30
HYUNDAI ROBEX35
CAT 303C CR/ 303.5C CR
KOMATSU PC10/12/15/20/27
DOOSAN DAEWOO DH30 DSL602 SOLAR30/035
(3) Main technical parameters on excavator concrete breaker
| Model | HY53 | HY68 | HY75 | HY85 | HY100 | HY120 |
| Breaker shell weight (KGS) | 60 | 100 | 200 | 400 | 450 | 500 |
| Total weight(KG) | 140 | 264 | 345 | 493 | 736 | 1374 |
| Size (MM) | 830*290*570 | 950*330*700 | 1140*370*740 | 1270*370*800 | 1340*430*970 | 1475*530*1000 |
| Driving oil pressure (KG/CM2) | 90-120 | 110-140 | 120-150 | 130-160 | 150-170 | 150-170 |
| Hydraulic oil flow (L/MIN) | 25-50 | 40-70 | 50-90 | 60-100 | 80-110 | 90-120 |
| Striking frequency (BPM) | 600-1200 | 500-900 | 400-800 | 400-800 | 350-700 | 350-650 |
| Soft hose diameter (INCH) | 1/2 | 1/2 | 1/2 | 3/4 | 3/4 | 3/4 |
| Drill rod diameter (MM) | 53 | 68 | 75 | 85 | 100 | 120 |
| Drill rod weight (KG) | 12 | 16 | 22 | 48 | 50 | 120 |
| Applicable carrier weight (T) | 2.0-4.0 | 4-7 | 6-9 | 7-14 | 11-16 | 12-18 |
(4) FAQ
1. Q: Are you a direct factory?
A: Yes, we are one big factory in China. And comprehensive strength of our company ranks top 3 in China market.
2. Q: Do you provide on-site installation service?
A: Yes, on-site installation service is available. And currently we are looking for wholesale distributors worldwide. In the coming future, our local distributors could serve you very soon in 24 hours
3. Q: Could I be your agent?
A: Yes, it is possible for you to be our agent overseas. For more details, please contact Lisa by whatsapp: 0086-17788159708
4. Q: How do you ship the concrete structures demolition hammers?
A: Usually we will cover demolition hammers with plastic film firstly, then load them into the container.
5. Q: When you will deliver the products after we place one order?
A: Usually 3-10 working days for the standard size. For customized hydraulic hammers, about 15 days
6. Q: What is your payment method?
A: L/C, T/T available for the payment. Usually 30% TT as deposit, 70% blanced by TT before shipping
7. Q: What is your quality warranty period?
A: For the complete hydraulic breakers, 6 months-12 months quality warranty period. But quick-wearing
(6) About transportation of excavator concrete breaker
Sea transportation
Air transportation
Truck transportation
Railway transportation
